Super Low Temperature Resistant Wire Spiral Hydraulic Rubber Hose
LT591Application： suitable for use under cryogenic petroleum base hydraulic oilTube ：The hose is composed of special composite rubber inner glue with excellent resistance to Reinforcement：ultra-low temperature and good oil resistance, steel wire braid strengthening layerCover：special composite rubber outer rubber with excellent resistance to ultra-low temperature and good resistance to weatherTemperature range：55 ℃ ~ 100 ℃
| SIZE (Dash) |
SIZE (in.) |
I .D. (mm) |
O.D. (mm) |
Max.W.P. |
B.P. |
Min. B.R. |
| Min |
Max |
Max |
MPa |
MPa |
(mm) |
| 8 |
1/2 -4S |
12.8 |
13.5 |
21.0 |
42 |
168 |
190 |
| 10 |
5/8-4S |
15.9 |
16.6 |
24.6 |
42 |
168 |
200 |
| 12 |
3/4-4S |
18.8 |
19.6 |
29.2 |
42 |
168 |
224 |
| 16 |
1 - 4 S |
25.0 |
25.8 |
36.0 |
42 |
168 |
272 |
| 20 |
11/4-4S |
31.6 |
32.6 |
42.9 |
35 |
140 |
420 |
| 24 |
11/2-4S |
37.7 |
38.8 |
49.8 |
35 |
140 |
500 |
| 20 |
11/4-6S |
31.6 |
32.6 |
48.0 |
42 |
168 |
420 |
| 24 |
11/2-6S |
37.7 |
38,8 |
54.0 |
42 |
168 |
500 |
