150 PSI Premium Paper Mill/Creamery Wash Down Hose With Tapered Nozzle
LT1002-A/LT1002-BApplications:For general wash down service, using hot and cold water in paper mills and in food and dairy plants
Tube:White EPDM
Reinforcement:High tensile textile cords
Cover:White or green EPDM-heat, abrasion and ozone resistant
Working Pressure:Constant Pressure-10 Bar (150 PSI)
Temperature Range:-40° F(-40° C) to 248° F(+120° C)
Specifications |
Series |
I.D.
(in.) |
I.D.
(mm) |
O.D.
(in.) |
O.D.
(mm) |
Max.W.P. (psi)
|
W.
(kg/m) |
LT1002A/B-075 |
3/4 |
19 |
1.22 |
31 |
150 |
0.65 |
LT1002A/B-100 |
1 |
25 |
1.46 |
37 |
150 |
0.80 |
LT1002A/B-125 |
11/4 |
32 |
1.81 |
46 |
150 |
1.16 |
LT1002A/B-150 |
11/2 |
38 |
1.97 |
52 |
150 |
1.35 |
